─ 57 ─
Double Pulley Assy
Lat Pulldown / Vertical Row Exploded View and Parts List
ITEM NO.
Description QTY
1 Double Pulley 1
2 3.5" Pulley 2
3 Hex Head Bolt M10*50 2
4 Flat Washer Φ11*Φ20*2 4
5 Nylon Lock Nut M10 2
Pulley Bracket ASSY
ITEM NO.
Description QTY
1 Pulley Bracket 1
2 3.5" Pulley 1
3 Hex Head Bolt M10*50 1
4 Flat Washer Φ11*Φ20*2 2
5 Nylon Lock Nut M10 1
