Impulse ES3000 User Manual

─ 58 ─
FOAM Frame ASSY
Lat Pulldown / Vertical Row Exploded View and Parts List
ITEM NO.
Description QTY
1 FOAM Frame 1
2 Nut 2
Pulley Bracket W/Shaft ASSY
ITEM NO.
Description QTY
1 Pulley Bracket W/Shaft 1
2 3.5" Pulley 1
3 Hex Flanged Nut 1/2"-13 2
4 Hex Head Bolt M10*50 1
5 Flat Washer Φ11*Φ20*2 2
6 Nylon Lock Nut M10 1
