Assembly
─ 70 ─
1. Attach the LEG EXT/LEGCUR & MULTI PRESS to the Middle Frame II ASSY (#7)
using:
● eight M10*75 Hex Head Bolt (#116)
● sixteen Φ11*Φ20*2 Flat Washer (#105)
● eight M10 Nylon Lock Nut (#115)
2. Attach the Cable 3 (#51) & Cable 4 (#84) to the Top Frame II ASSY (#5) & the Top
Plate (#29).
Note: Wrench Tighten bolts and Nylon Lock Nuts.
STEP 8
1. Attach two Cup Holder (#14) to the two Iron shroud (#30) using:
● four M5*12 Screw (#108)
● eight Φ5.5*Φ10*1 Washer (#107)
● four M5 Nylon Lock Nut (#109)
2. Attach six Shaft (#21) to the Middle Frame II ASSY (#7) using:
● six Φ8 Spring Washer (#112)
3. Attach three L Plate (#20) to the Top Frame II ASSY (#5) & two Small Top Frame
ASSY (#12) using:
● six M8*20 Hex Head Bolt (#113)
● six Φ8 Spring Washer (#112)
● six Φ9*Φ16*1.6 Washer (#111)
4. Attach three Iron shroud (#30) to the Middle Frame II ASSY (#7) & three L Plate
(#20) using:
● twelve M8*15 Button Head Cap Screw (#126)
● twelve Φ9*Φ22*1.6 Flat Washer (#124)
5. Attach two Top Shroud Plate (#31) to the Top Frame II ASSY (#5) using:
● two M8*15 Button Head Cap Screw (#126)
● two M8*25 Button Head Cap Screw (#125)
● two Nylon Spacer (#110)
● four Φ9*Φ22*1.6 Flat Washer (#124)
Note: Wrench Tighten bolts and Nylon Lock Nuts.
STEP 9
