─ 6 ─

Exploded View and Parts List

Overall

ItemNo.

Grade No. Part No. Description QTY

1 1 IF2011B01ASSY Main Frame ASSY 1

2 2 IF2011B02ASSY Rear Base ASSY 1

3 3 IF2011B03ASSY Shaped Base ASSY 1

4 4 IF2011B04ASSY Seat Pad Support ASSY 1

5 5 IF2011B05ASSY Back Pad Support ASSY 1

6 6 IF2011B06ASSY Adjustable Back Pad Support ASSY 1

7 7 EF90100800 Head Pad 1

8 8 EF90100900 Back Pad 1

9 9 EF90101000 Seat Pad 1

10 10 PNLM12*125DHS2 Button Head Cap Screw M12*125 3

11 11 PNLM12*75DHS2 Button Head Cap Screw M12*75 2

12 12 PNLM10*70DHS2 Button Head Cap Screw M12*75 6

13 13 PNLM10*25DHS2 Button Head Cap Screw M10*25 2

14 14 GB70M8*20DHS2 Socket Head Cap Screw M8*20 1

15 15 DQ12DHS2B Flat Washer Φ13*Φ26*2 10

16 16 DQ10DHS2A Flat Washer Φ11*Φ23*2 10

17 17 GB958DHS2 Flat Washer Φ9*Φ16*1.6 2

18 18 NM12DHS2 Nylon Lock Nut M12 5

19 19 NM10DHS2 Nylon Lock Nut M10 2

20 20 NM8DHS2 Nylon Lock Nut M8 1
