Impulse IF9325 - Adjustment Column ASSY; Handdle Frame ASSY

12
Exploded View and Parts List
Adjustment Column ASSY
Handdle Frame ASSY
ItemNo.
Grade No. Part No. Description QTY
1 9.1 IF93271800 Sliding Adjustment Column 1
2 9.2 ES70300800ASSY Sliding Carriage 1 ASSY 1
3 9.3 IT952520V1ASSY Double Pulley Bracket ASSY 1
4 9.4 GB5780M8*90DS20 Hex Head Cap Screw M8*90 1
5 9.5 GB958DS2 Flat Washer Φ9*Φ16*1.6 2
6 9.6 NM8DS2 Nylon Lock Nut M8 1
7 9.7 IF93272200ASSY Safety Pin ASSY 1
ItemNo.
Grade No. Part No. Description QTY
1 10.1 IF93271500 Handdle Frame 1
2 10.2 BNH0573 Plug 1
