Impulse IF9325 - Assembly; STEP 1

STEP 1
1. Attach the Bottom Cross Frame ASSY (#2) to the Main Frame ASSY (#1) using:
four M10*80 HHB (#25)
four M10 Nylon Lock Nut (#28)
eight Φ11*Φ20*2 Flat Washer (#21)
2. Attach two Hanger Column (#19) and two Spring Washer Φ8 (#22) to the Main Frame
ASSY (#1).
Note: Hand Tighten Bolts and Nylon Lock Nuts until Machine is Fully Assembled.
