Impulse IF9325 User Manual

6
Exploded View and Parts List
Overall
ItemNo.
Grade No. Part No. Description QTY
1 1 IF932501ASSY Main Frame ASSY 1
2 2 IF932502ASSY Bottom Cross Frame ASSY 1
3 3 IF932503ASSY Top Cross Frame ASSY 1
4 4 IF932504ASSY Right Front Cross Frame ASSY 1
5 5 IF932505ASSY Left Front Cross Frame ASSY 1
6 6 IT95014200 Top Plate 1
7 7 IT951550ASSY Pulley Frame ASSY 1
8 8 TS10001600V1 Guide Rod 2
9 9 IF932718ASSY Adjustment Column ASSY 1
10 10 IF932715ASSY Handdle Frame ASSY 2
11 11 IF93253300 Cabble ASSY 1
12 12 IT95255200 D-Strap 1
13 13 V310800 Leg EXT/Curl Strap 1
14 14 SG500110400V5 4.5" Pulley 2
15 15 M01004800V3 3.5" Pulley 3
16 16 IT80023000 Weight Rubber Bumper 2
17 17 IT95016100 Guide Rod Fixing Sleeve Φ25*Φ19*45 2
18 18 IT90012000V1 Selector Pin W/Coil 1
19 19 IT95274400 Hanger Column 2
20 20 HFOPT900-04A0602 Spring Φ15.5*Φ1.5*36 2
21 21 GB9510DS2 Flat Washer Φ11*Φ20*2 45
22 22 GB938DS12 Spring Washer Φ8 2
23 23 GB9310DS12 Spring Washer Φ10 1
24 24 GB5780M10*75DS20 Hex Head Bolt M10*75 6
25 25 GB5780M10*80DS20 Hex Head Bolt M10*80 8
26 26 GB5780M10*65DS20 Hex Head Bolt M10*65 5
27 27 GB5780M10*85DS20 Hex Head Bolt M10*85 4
28 28 NM10DS2 Nylon Lock Nut M10 22
29 29 IF93272100 Stop Rubber Bumper 2
30 30 HLG8N9 Gear Hook 1
31 31 LW200BS Wrench Φ6*117 1
32 32 NBS0.188DHS Hex KeyS=3/16" 1
33 33 YHY Lube 1
