Impulse IF9325 User Manual

STEP 4
1. Attach:
two Guide Rod Φ19* 1829 (#8) two Weight Rubber Bumper (#16)
two Weight Stack Space (#80) fifteen Weight Plate 10LBS (#81)
one Top Plate (#6)
to the Main Frame ASSY (#1) using:
two Guide Rod Fixing Sleeve Φ25*Φ19*45 (#17)
two Spring (#20)
2. Attach the Selector Pin W/Coil (#18) and one Pulley Frame ASSY (#7) to the Top Plate (#6).
Assembly
21
Here is the assembly instruction for 160LBS Weights !
Grade No.
Part No. Description QTY
80 FEWS01ASSY Weight Stack Space 2
81 FE97193100 10LBS Weight Plate 15
