Impulse SL7046 User Manual

12
Exploded View and Parts List
Main Frame ASSY
Item No. Grade No. Part No. Description QTY
1 4.1 SL70460400ASSY Main Frame Sub ASSY 1
2 4.2 SL70461200ASSY Swinging Support Frame ASSY 1
3 4.3 SL70412500 Spring 1
4 4.4 PBF9001803 Ball 1
5 4.5 SL704605ASSY Sliding Rack ASSY 1
6 4.6 SL70460600 Back Pad Frame 1
7 4.7 SL704107ASSY Support Frame ASSY 2
8 4.8 SL70461500 Adjustable Tube 1
9 4.9 IF93272100 Limit Bumper 1
10 4.10 QD22-420-14 Gas Spring 1
11 4.11 SL70462200 Pivot Shaft Φ25.4 1
12 4.12 IN-D21202000 Aluminum End Cap Φ38*Φ10.5*8 6
13 4.13 GB70M12*100DHS20 Socket Head Cap Screw M12*100 1
14 4.14 GB70M10*75DHS20 Socket Head Cap Screw M10*75 2
15 4.15 GB70M10*70DHS20 Socket Head Cap Screw M10*35 2
16 4.16 CNLM10*30*30DS20NL Flat Head Cap Screw M10*30 6
17 4.17 GB9512DHS2 Flat Washer Φ13*Φ24*1.5 2
18 4.18 GB9510DHS2 Flat Washer Φ11*Φ23*2 8
19 4.19 NM12DHS2 Nylon Lock Nut M12 1
20 4.20 NM10DHS2 Nylon Lock Nut M10 4
21 4.21 NM8DHS2 Nylon Lock Nut M8 2
