Impulse SL7046 - Page 11

11
Exploded View and Parts List
Sliding Rack ASSY
Item No. Grade No. Part No. Description QTY
1 4.5.1 SL70460500 Sliding Rack 1
2 4.5.2 KPSOB2100V1 Tube Guide □63.5*□50.8 2
3 4.5.3 VLP8000 Pipe Plug□50*100 1
4 4.5.4 M02502000 Bushing Φ38*Φ32*Φ25.4*18 2
5 4.5.5 IT95251600 Spring Pin 1
Support Frame ASSY
Item No. Grade No. Part No. Description QTY
1 4.7.1 SL70410700 Support Frame 1
2 4.7.2 M02502000 Bushing Φ38*Φ32*Φ25.4*18 4
