5.0 Error Codes
Table 5.1 Error Codes
Watchdog Re-start (Processor Crash) If the condition recurs, call Technical
Service.
Memory Error at start-up
(User programming is erased; Factory program defaults are re-loaded)
Keyboard Error at Start Up
(Up or Down Key, or more than one key is being pressed during Power-Up)
Input Calibration Error (Input signal differential too large)
Synchro input signal not present
Analog minimum position cannot be displayed with the number of left digits
set. (Increase number of left digits in OP 4)
Analog maximum position cannot be displayed with the number of left digits
set. (Increase number of left digits in OP 4) OR greater than 65,535 turns
required to span Analog Min. to Analog Max. (Increase counts per turn (OP 3)
or reduce analog output span.)
Low Relay limit position cannot be displayed with the number of left digits
set. (Increase number of left digits in OP 4)
High Relay limit position cannot be displayed with the number of left digits
set. (Increase number of left digits in OP 4) OR limit not useable, greater than
65,535 turns required to span between LO & HI relay limits (Increase counts
per turn (OP 3) or reduce span between relay limits)
Preset position cannot be displayed with the number of left digits set.
(Increase number of left digits in OP 4) OR greater than 65,535 turns
required to reach Analog Min. or Analog Max. from present position (increase
counts per turn (OP 3) or reduce analog output span.)
Analog output calibration mode not enabled (Change OP 30 to “On”)
Wrong combination of serial port settings (Check parity, data & stop bits)
Non-Linear Table duplicate data point entered
Non-Linear Table full (100 data point pairs max.)
Display over-range (Increase number of left digits in OP 4)
