Incon 1250B User Manual

9
2.0 PROGRAMMING
The Model 1250B has three methods of programming, numeric menu, alphanumeric
menu, and serial port programming commands. Depending upon the serial port option
ordered, the serial programming commands will be either RS-232 ASCII commands or RS-
485 packet commands. (See Table 2.1 for a full listing of all programming menu items. See
Figure 2.1 for a simple programming flowchart. See Table 2.2 for a full listing of all serial
port programming commands and syntax.)
To access the numeric or alphanumeric programming menu, press the MENU key for
several seconds until the display goes blank, then press the SELECT/ENTER key. The
display should read “OP 0”. The default menu is the numeric menu. To choose the
alphanumeric menu, press the DOWN key to select OP 99. Press the SELECT/ENTER key,
the display should read “to OP”. Press the UP key. The display should read “run”. You are
now in the alphanumeric menu mode.
To change a parameter using the numeric or alphanumeric menus, select the parameter
to be changed from the menu, press the SELECT/ENTER key. The parameter’s present
setting will now be displayed. You can change the setting by pressing the UP or DOWN key.
To store the new setting, press the SELECT/ENTER key. The display will return to the
menu.
Table 2.1 Numeric and Alphanumeric Menu Items:
Num-
eric
Alpha-numeric
Protocol
Default
Value:
Programmable Range:
Function:
OP 0
Run
Press the SELECT/ENTER key to exit the
Program mode
OP 1
rLY E
OFF
On or OFF
Enables the High/Low Relays
OP 2
Func
1
1, 2, 16, 17, 18, 19, 20, 21
Select Operating Mode (see page 12)
OP 3
CPt
360
-99999 to +99999
Scaled Mode: Counts per Turn
OP 4
LEFtd
4
0 to 5
Scaled Mode: Sets the number of digits to
the left of the decimal point
OP 5
An L
0.0000
-99999 to +99999
Scaled Mode: Analog output low limit
OP 6
An H
360.00
-99999 to +99999
Scaled Mode: Analog output high limit
OP 7
rLY L
0.0000
-99999 to +99999
Scaled Mode: Relay Low limit
OP 8
rLY H
8.0000
-99999 to +99999
Scaled Mode: Relay High limit
OP 12
tnS F
0.0000
0.0000 to +3600.0
Rotation Rate Filter Threshold
OP 13
FLttH
0.0000
0.0000 to +99999
Averaging Filter Threshold
OP 14
FdPth
0.0000
0 to 128.00
Averaging Filter Depth
OP 17
SEt P
0.0000
-99999 to +99999
Scaled Mode: Set preset position
OP 18
Ld P
Ld
Scaled Mode: Loads preset position into
memory
OP 19
CL P
CL
Scaled Mode: Clears position offset
OP 20
tAPS
33
2 to 100
Segmented Mode: Number of taps
OP 21
D SEG
10.000
-99999 to +99999
Segmented Mode: Degrees per tap
OP 22
NEu
1
0 to 9
Segmented Mode: Number of neutral taps
OP 23
N St
0-1
Any valid tap number
Segmented Mode: Sets neutral start tap
OP 24
rL Lt
-16
Any valid tap number
Segmented Mode: Sets low relay limit tap
