TS-TPI Setup Programming Page 23 - 7
23
—
PUMP N Menu
continued —
HEIGHT (user entry)
Here is the PUMP N menu, showing TANK
and HEIGHT menus....
Press the
M2
key to display the HEIGHT
PUMP N user entry field ....
The default HEIGHT of ‘+7.0’ (inches) is
displayed ....
Press the
M4
key to backspace and erase
the ‘+7.00000’ default height number.
Use the keypad to enter the height value.
Press the
ENTER
key to accept data entry.
The display returns to the PUMP N menu
showing TANK and HEIGHT.
To repeat these steps for the next pump:
• Press the CANCEL key to display the TPI PUMP menu, which displays AUTO CFG, PUMP 1,
PUMP 2 ....
• Repeat each Pump N Menu step for every PUMP number.
When these entries are completed ....
• Press the CANCEL key to display the main TPI menu, which displays ENABLE, PUMP and
GROUP.
— Proceed to the next menu - TPI Group —
M1 M2 M3 M4
HEIGHT PUMP 1 NUMERIC
+7.00 BACKSPACE
M1 M2 M3 M4
The value is the distance (in inches or
centimeters) between the bottom of the PUMP
to the bottom of the TANK. This allows the
pump height to be set by the user, which affects
the handling of the DRY TANK, BLOCKED
INTAKE, and PUMP IN WATER alarms. This
variable defaults to 7 inches and is user-
programmable. The range allowed is 0 to 65.
To Next Page
