Page 23 - 8 Tank Sentinel Setup Programming Guide
TPI Group Menu
• TYPE “READ ONLY”
• MODE (user entry)
• RESERVE (user entry)
TYPE “READ ONLY”
The main TPI menu displays ENABLE,
PUMP and GROUP ....
Press the
M3
key to display the TPI GROUP
menu ....
Here is the TPI GROUP menu displaying
GROUP numbers 1 to 4 ....
Press the (
M
) key of the group number to be
displayed. For this example, press
M2
to
display the GROUP 2 menu ....
Here is the GROUP 2 menu displaying TYPE
and MODE ....
Press the
M1
key to display the TYPE of
group as detected during Auto-Configuration.
This is a READ ONLY field.
In this example, the type ‘MAST SLAV’ is
displayed ....
Press the
CANCEL
key to return to the
GROUP 2 menu.
To repeat the user entry steps for each
group, press CANCEL again to display the
TPI GROUP menu.
— Proceed to the next menu - MODE —
TYPE GROUP 2 READ ONLY
MAST SLAV
Please read the Notes on the following
page to gain a better understanding of the
Mode and Reserve features.
