27 Page 27 - 4 Tank Sentinel Setup Programming Guide
DISPLAY Navigation/Descriptions (C ONTINUED ... FROM PREVIOUS PAGE )
AL-LLD — shows the current status of the line leak sensing units via the LS 300
Special AL-LLD navigation —
• Press the ( M ) key aligned below AL-LLD,
• Press the ( M ) key under each LINE number,
(In this example, press the M1 key for LINE 1 data)
AL-LLD DISPLAY example:
Each controller type will vary in the available data that can be displayed.
The example below is for the SCI controller.
Here is typical information displayed for each line number....
See Appendix E for detailed explanations of this data.
— Proceed to Chapter 28 - DIAG Menu —
SELECT MENU OPTION
AL-LLD
M1 M2 M3 M4
SELECT LINE
LINE 1 LINE 2
M1 M2 M3 M4
LINE 1 STATUS PRESSURE TEST STATUS
LINE 1 OK 30.5 0015 0800
