Incon task sentinel TS-504 User Manual

System Setup Page 1 - 3 1
S
YSTEM Menu (C ONTINUED ... FROM PREVIOUS PAGE )
NO. SENSORS (enter the number of Leak Detection Sensors)
NUMBER OF SENSORS
12 (for TS-1001, 504, 750)
(0 thru N) enter the total number of Sensors.
24 (for TS-2001, 508) (also enter all unused channels between the lowest to
highest channel (also see SENSORS menu)
Press
ENTER
to accept this data.
NO. METERS (devices used with TS-DIM)
NUMBER OF METERS
0
enter number of meters.
Press
ENTER
to accept this data.
BUSY ENA
BUSY ENABLED
(dispenser supports ‘busy’ signal to ATG)
NO Use
UP/DOWN
keys to choose setting.
YES Press
ENTER
to accept this data.
U THRESH (volume allowed pumped before Catastrophic Leak alarm)
USER THRESHOLD
+0
1 to +9999 volume units.
Press
ENTER
to accept this data.
LIMITS
LIMITS
(set leak limits for after hours sentinel mode – also see
LEAK LIM menu)
LEAK LIMIT
+2.0
0.2 to +10.0 volume units.
Use keypad to input sentinel mode leak rate.
Press
ENTER
to accept this data.
LEAK OG (assign leak alarm to an OG (
NONE
, A to FF, or ALL)
LEAK LIMIT OUTPUT GROUP (32 OGs available... see Worksheet #1-1 )
NONE Not assigned to an Output Group (OG)
GROUP A thru FF One OG selected ( A = 1 ST OG, FF = 32 ND OG )
ALL GROUPS All OGs selected
Use
UP/DOWN
keys to choose an OG.
Press
ENTER
to accept this data.
THEFT LIM (enter theft limit for all tanks)
THEFT LIMIT
+10.0
1 to +9999 volume units.
Press
ENTER
to accept this data.
THEFT OG (assign theft limit alarm to an OG ( NONE , A to FF, or ALL
THEFT LIMIT OUTPUT GROUP Output Groups)(32 OGs available... see Worksheet #1-1 )
NONE Not assigned to an Output Group (OG)
GROUP A thru FF One OG selected ( A = 1 ST OG, FF = 32 ND OG )
ALL GROUPS All OGs selected
Use
UP/DOWN
keys to choose an OG.
Press
ENTER
to accept this data.
