Incon TS-STS - Leak Testing Operations and Reports; Viewing Alarms and Warnings; Generating Reports; Report Types and Data Overwrite

Leak Testing /
Console Operation Continued...
ACK
SHIFT
SELECT SUMP REPORT
TEST LEVEL
M1
LEFT
M2
RIGHT
M3 M4
J W
REPORT
9
SELECT SUMP
SUMP 1 SUMP 2 SUMP 3 ALL
M1
LEFT
M2
RIGHT
M3 M4
SELECT ALARM TYPE
SYSTEM SUMP ALL
M1
LEFT
M2
RIGHT
M3 M4
SELECT (SYSTEM / SUMP) ALARM STATUS
ACTIVE CLEARED HISTORY
M1
LEFT
M2
RIGHT
M3 M4
6.) To view an alarm/warning, press the M1 or M2 Key under the
word Alarm / Warning. While viewing the alarm, press the ACK
SHIFT key at the keypad to acknowledge. Cleared and
transient alarms should be acknowledged prior to starting
another test.
7.) Press the Report key at the keypad to show various report
choices.
—
❖
—
Reports
4
INCON
INTELLIGENT CONTROLS INC.
P.O. BOX 638
SACO ME 04072
1-800-984-6266
10/31/2001 12:15 PM
SUMP LEAK TEST REPORT
SUMP 2
TEST STARTED 12:00 PM
TEST STARTED 10/31/01
BEGIN LEVEL 7.0230 IN
END TIME 12:15 PM
END DATE 10/31/01
END LEVEL 7.0209 IN
LEAK THRESHOLD 0.002 IN
TEST RESULT: FAILED
Reports can printout automatically or on
demand from the keypad. The
Sump Leak Test and Alarm
Reports print automatically.
The other reports, such as
the Sump Level Reports,
Alarm Reports, and Sump
Test Reports can be printed
on demand.
Press the menu select keys
and choose the type of report
that you wish to printout.
Alarm reports will print as
soon as an alarm is detected.
Leak test reports print
automatically after the leak test is finished. Note that
when a new leak test is complete the data will
overwrite a previous result.
Of the three reports shown here, one is a Level
Summary report and two are Sump Leak Test
Reports.
Up to 4 sumps can be leak-tested at the same
time.
REPORTS continued...
INCON
INTELLIGENT CONTROLS INC.
P.O. BOX 638
SACO ME 04072
1-800-984-6266
10/31/2001 12:15 PM
SUMP LEAK TEST REPORT
SUMP 1
TEST STARTED 12:00 PM
TEST STARTED 10/31/01
BEGIN LEVEL 2.0120 IN
END TIME 12:15 PM
END DATE 10/31/01
END LEVEL 2.0120 IN
LEAK THRESHOLD 0.002 IN
TEST RESULT: PASSED
INCON
INTELLIGENT CONTROLS INC.
P.O.. BOX 638
SACO ME 04072
1-800-984-6266
10/31/2001 11:58AM
SUMP LEVEL REPORT
SUMP 1 2.012 IN
SUMP 2 7.201 IN
SUMP 3 3.218 IN
SELECT REPORT
SUMP ALARM
M3
M4
M2
RIGHT
M1
LEFT
Pg 7
1.
2.
3.
