Description of the
appliance
The number and type of wash cycles and options may vary depending on the dishwasher model.
Overall view
Control panel
button and indicator
lights Start/Pause
ON/OFF/Reset button
Select wash cycle button
Delayed Start option button
Multi-Functional Tablets
option button (Tabs)
Half Load/Extra Light options button
Display
1. Upper rack
2. Upper spray arm
3. Tip-up dispensers
4. Rack height adjuster
5. Lower rack
6. Lower spray arm
7. Washing filter
8. Salt dispenser
9. Detergent dispenser and rinse-aid dispenser
10. Data plate
11. Control panel***
Display
Delayed Start option indicator light
Low Rinse-Aid indicator light
Low Salt indicator light
Washing indicator light
Drying indicator light
Half Load/Extra Light
options indicator light
Multi-Functional Tablets
option indicator light (Tabs)
Remaining time indicator
Wash cycle
number
