Indesit IS67G5PHX/UK - Gas Section

*with dry gas 15°C 1013 mbar
** Propane P.C.S=50,37 MJ/Kg
*** Butane P.C.S=49,47MJ/kg
Natural G20 P.C.S=37,78Mj/m³
Table of burner and nozzle specifications
The front right hob burner injector should be used as the pressure test point.
Characteristics of the gas section
Model Gas section
Rated power
kW (1)
II2H3+
(1) The values in g/h refer to the capacities with liquid gas (Butane, Propane).
IS67G5PHX/UK
Gas category
8,00 (G20)
8,00
(582 g/h-G30)
(571 g/h-G31)
8
Liquid Gas Natural Gas
Thermal Power
kW (p.c.s*)
By-Pass
1/100
(mm)
Nozzle
1/100
(mm)
Flow
g/h
Nozzle
1/100
(mm)
Flow
g/h
Burner Diameter (mm) Nominal Reduced *** **
Rapid (R) 100 3.00 0.70 41 86 218 214 116 286
Semi Rapid
(Medium) (S)
75 2.00 0.40 30 70 145 143 103 190
Auxiliary
(Small) (A)
55 1.00 0.40 30 50 73 71 79 95
Supply
Pressures
Nominal (mbar)
Minimum (mbar)
Maximum
28-30
20
35
37
25
45
20
17
25
