Hydraulic unit C100, C200
a
Filler neck
b Base plate of hydraulic unit
c Level control
d Drain plug
e Accumulator drain valve
Remove the hydraulic unit base plate (b) and clean the hydraulic fluid tank.
3. Replace the seal at the hydraulic unit base plate (b).
4. Screw on the hydraulic unit base plate (b) again, paying attention to the correct
seating of the seal and the base plate (b).
5.
Dispose of the fluid in the filter bowl (Y); do not refill into the
hydraulic tank.
Maintenance Summary - 4.000 Operating hours
89
Maintenance Instructions
C100
LP1602.10091 - 05.06.2019
