INETVU® MOBILE SYSTEM QUICK START – HUGHES KA
1.8 USB Interface Connection – (HN_KA) 9600/9800 System Wiring
4. USB Interface System Wiring Diagram for 9600/9800 Modems
*Recommended for proper grounding of iNetVu
®
systems.
STRAIGHT/
X-OVER
NETWORK
CABLE
24 VDC Input
(option)
USB CABLE
GPS /Glonass
Antenna
SENSOR
CABLE
MOTOR
CABLE
TX
RG6 Coaxial Cable
Network Cable
Power Cable
Sensor Cable
Motor Control Cable
USB Cable
HN 9600/9800
*Ground
protection
External
grounding
connection
RX
OUT
SAT
192.168.0.2
90 - 264 VAC
!
192.168.0.1
iNetVu® Mobile
Platform
