iNetVu 7000 Series Quick Start

INETVU® MOBILE SYSTEM QUICK START – HUGHES KA
1.7 Network Interface Connection – (HN_KA) 9600/9800 System Wiring
3. Network Interface System Wiring Diagram for Hughes 9600/9800 Modems
*Recommended for proper grounding of iNetVu
®
systems.
STRAIGHT/
X-OVER
NETWORK
CABLE
SENSOR
MOTOR
CONTROL
TX
HN 9600/9800
90 - 264VAC
!
RG6 Coaxial Cable
Network Cable
Power Cable
Sensor Cable
Motor Control Cable
USB Cable
Router /
Switch
*Ground
protection
External
grounding
connection
24 VDC Input
(option)
SAT
LAN 1
PORT
Modem
Example:
70.232.247.49
Router:
WAN IP: 70.232.247.50
SUB: 255.255.255.0
LAN IP: 192.168.0.1
SUB: 255.255.255.0
7000 CTRL:
DHCP
OR
Static:
IP:
192.168.0.2
SUB:
255.255.255.0
GW:
192.168.0.1
PC: DHCP
OR
Static:
IP:
192.168.0.3
SUB:
255.255.255.0
GW:
192.168.0.1
PC: DHCP
OR
Static:
IP:
192.168.0.4
SUB:
255.255.255.0
GW:
192.168.0.1
iNetVu® Mobile
Platform
GPS/Glonass
Antenna
