INETVU® MOBILE SYSTEM QUICK START – HUGHES KA
1.6 Network Interface Connection – Hughes (HN_KA) System Wiring
2. Network Interface System Wiring Diagram for Hughes 9200/9400 Series Modems
*Recommended for proper grounding of iNetVu
®
systems.
STRAIGHT/
X-OVER
NETWORK
CABLE
SENSOR
MOTOR
CONTROL
TX
HN 9200/9400
90 - 264VAC
!
RG6 Coaxial Cable
Network Cable
Power Cable
Sensor Cable
Motor Control Cable
USB Cable
Router /
Switch
*Ground
protection
External
grounding
connection
24 VDC Input
(option)
RX
OUT
RX IN
SAT
IN
SAT
OUT
RX
LAN 1
PORT
Modem
Example:
70.232.247.49
Router:
WAN IP: 70.232.247.50
SUB: 255.255.255.0
LAN IP: 192.168.0.1
SUB: 255.255.255.0
7000 CTRL:
DHCP
OR
Static:
IP:
192.168.0.2
SUB:
255.255.255.0
GW:
192.168.0.1
PC: DHCP
OR
Static:
IP:
192.168.0.3
SUB:
255.255.255.0
GW:
192.168.0.1
PC: DHCP
OR
Static:
IP:
192.168.0.4
SUB:
255.255.255.0
GW:
192.168.0.1
iNetVu® Mobile
Platform
GPS/Glonass
Antenna
