INETVU® MOBILE SYSTEM QUICK START – HUGHES KA
1.4 System Wiring with Hughes (HN_KA) Service
1.5 USB Interface Connection – System Wiring with Splitter
1. USB Interface System Wiring Diagram for 9200/9400 Series Modems
*Recommended for proper grounding of iNetVu
®
systems.
STRAIGHT/
X-OVER
NETWORK
CABLE
24 VDC Input
(option)
USB CABLE
SENSOR
CABLE
MOTOR
CABLE
TX
RG6 Coaxial Cable
Network Cable
Power Cable
Sensor Cable
Motor Control Cable
USB Cable
HN 9200/9400
*Ground
protection
External
grounding
connection
RX
RX
IN
RX
OUT
SAT
OUT
SAT
IN
LAN 1
PORT
192.168.0.2
90 - 264 VAC
!
192.168.0.1
iNetVu® Mobile
Platform
GPS /Glonass
Antenna
