Infa Group Infa Secure CS8813 - Infant Car Seat

14
Figure 1
Adjuster Assembly Location
Change Adjuster Position
Infant Car Seat
Infant Seat
Figure 2
Figure 3
Step 1:
Lower the headrest .
Fold the cover forward expose the tether anchor
plates.
Step 2:
Repeat of the other side.
Step 4:
Insert the plates back into the shell and ensure the
tether plates are attached as shown in Figure 2.
Step 5:
Reposition the cover .
Step 6:
From the inside of the shell, pull the 3 bar plate and
push through the slot .
Step 3:
Note:
You can switch the top tether to position the
adjuster on the other side of the vehicle which will
provide you with convenient access to adjuster .
Note:
The position of the adjuster (Top Tether Strap) can
be changed to either side of the child restraint in
rearward facing mode.
Note:
The tether will “hang” as shown below .
