53
Step 2:
To Release Child
To releaseyourchild from therestraint simply press
theharness buckle and carefully remove your child
from therestraint (refer Figure1).
Use
Child Car Seat
Using Inbuilt Harness
IMPORTANT
!
provide extra support and comfort for small
babies. Discontinue use when the insert is a
babies/children.
Always adjust the height of the shoulder straps
as the child grows.
Step 3:
Adjusting Recline Angle
NOTE: To adjust the recline angle of the child seat
refer to “Converting to Child Car Seat” on page 38.
First loosen the seatbelt assembly, the Safe Grip Belt
Clamp may need to be removed & loosen the top tether strap.
At the front of the restraint is a GREY* lever. Pull the red* lever
forward and slide the restraint to obtain the desired
upright or reclined angle (refer Figure 1). *Colour may vary.
Reinstall the seatbelt and Safe Grip Belt Clamp if supplied.
(refer page 48) and retension both seatbelt & top tether.
Step 6:
Step 1:
Step 2:
Check the harness tightness by the PINCH TEST ,
this is acheived by pinching the harness webbing at
the shoulders (refer Figure 7).
• If you can pinch the harness strap, tighten more.
• If your ngers slip off, then the harness is tight
enough.
If required repeat Step 5.
NOTE: Pinch test is conducted only on harness
webbing (not over shoulder pads).
Figure 7
PINCH
TEST
Figure 1
Recline
Upright
Front
of Car
RED
LEVER
1
2
3
Figure 1
Step 1:
Harness straps should be loosened prior
to disengaging the buckle.
To Next Page
