Infa Group Infa Secure CS8813 - Anchorage Fittings

63
Attachment
Bolt
SIDE VIEW
UPPER ANCHORAGE FITTINGS 
FOR SEDANS ONLY
Anchorage Fittings
CHILD RESTRAINTS MUST NOT BE
ATTACHED TO UNSOUND METAL OR
WOOD OR SYNTHETIC
STRUCTURES. WHEN DRILLING THE
9MM HOLE DO NOT DRILL
THROUGH FUEL LINES, FUEL
TANKS, ELECTRICAL WIRING OR
RADIO SPEAKERS. WEBBING
STRAPS MUST BE PROTECTED
FROM SHARP CORNERS AND
EDGES.
THE ANCHOR FITTING MUST BE
USED ONLY AS DESCRIBED ABOVE.
IT MUST NOT BE HOOKED ONTO
ANY OTHER OBJECT.
Anchor
Fitting
Spacer(s)
(if required)
Vehicle
Trim
Reinforcing
Washer
Lock
Washer
Nut
FRONT OF VEHICLE
Vehicle
Metal 
Structure
WARNINGS
!
