Child Car Seat
Model CS8013
Forward Facing
11
12
13
14
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 58.
1. Shoulder Height Markers
2. Headrest Assembly
3.
4.
Headrest + Harness adjustment system
Harness Straps
5. Shoulder Pads
6. Harness Straps Buckle Pad
7. Padded Insert (if fitted)
8. Harness Adjuster
9. Harness Adjustment Strap
10. Comfort Cover Harness Adjustment Strap
11.
Safe Grip Red Belt Clamp (if supplied with restraint)13.
“FORWARD-FACING SEAT BELT PATH” Marker
(each side of restraint - coloured yellow)
14. Vehicle Seat belt
15. ISOFIX Compatible
Lower attacment Connectors (LAC)
Shoulder height markers may
be hidden under a headrest
10
1
2
3
4
5
6
7
8
9
Top Tether Assembly
• Tether Strap
• Adjuster
• Attachment Clip
• Anchor Fitting + Attachment Hardware
12.
15
ISOFIX
Compatible
