38
Determine whether your child requires the additional padding provided with this restraint, to
combinations.
Refer to the shoulder height labels (As shown
on pages 34 and 35). For Correct shoulder strap
slot height refer to pages 40 - 42.
IMPORTANT
!
Converting to Child Car Seat
Under the front of the restraint is a *GREY lever. Lift the
the lever to recline. (refer Figure 1) *Colour may vary
Rotate the restraint into the appropriate recline angle.
There are 3 Recline angles for Forward Facing.
NOTE: Forward Facing recline indicator is visible
(refer Figure 2)
Reclined Position
Selection of Appropriate Padding Combinations
Setup
Child Car Seat
Figure 1
1
2
3
1
2
3
4
Figure 2
Rearward facing
Forward facing
RECLINE LEVER
CS8813 Convertible Car Seat ISOFIX and seatbelt compatible
CS8913 Convertible Car Seat seatbelt compatible
LIFTLIFT
