6ED family - 2nd generation
Technical Description
Application Note 21 Rev. 1.3, 2014-03-23
AN-EICEDRIVER-6EDL04-1
Glossary and general terms
4 List of used parameters
4.1 General
big letters Time constant parameters
small letters Time varying parameters
italic letters physical parameters
upright letters components in circuits
Table 2 Used parameters
Parameter
Description
Parameter
Description
A
area
p, P
power
b, B
flux density
r, R
resistance
C
capacitance
t, T
time, time intervals
d, D
duty cycle
v, V
voltage
f
frequency
w, W
energy
i, I
current

efficiency
l, L
inductance
C
capacitor
L
inductor
D
diode
R
resistor
IC
integrated circuit
TR
transformer
AC
alternating current value
i
running variable
avg
average
in
input value
DC
direct current value
max
maximum value
BE
basis-emitter
min
minimum value
C
collector value
off
turn-off / off-state value
E
emitter value
on
turn-on / on-state value
G
gate value
out
output value
P
primary side value
p
pulsed
Pk
peak value
S
secondary side value
