Infinite Element - Page 12

22 23
WARNING: Make sure that the Element red connector is plugged into
the coaxial plug power pins labeled “1”. Incorrectly connecting the red
connector could cause permanent damage to the hand and Element.
Hand Only
CABLE HAS
BLACK STRIPE
CABLE HAS NO
BLACK STRIPE
1
22
CABLE HAS
BLACK STRIPE
CABLE HAS NO
BLACK STRIPE
M
1
2
Hand and Wrist
Ottobock Wrist (10S17) with MyoRotronic (13E205)
