Infinite Element - Specifications; Installation; Before You Begin

8 9
Dimensions (Element Box LxWxH) 38mm x 22.8mm x 3.85mm
Dimensions (IBT Electrodes LxWxH) 28.8mm x 16.8mm x 6.7mm
Temperature range (use) -10°C to +50°C (14°F to 122°F)
Temperature range
(transport/storage)
-20°C to +65°C (-4°F to 149°F)
Humidity range (use) 45% - 75%
Humidity range
(transport/storage)
15% - 93%
Atmospheric pressure range 860 hPa - 1060 hPa
Input voltage 5 to 10V
Maximum Output Current 3A
Compatible battery FlexCell
Recommended battery capacity Depends on terminal device. Contact
us for recommendations.
Expected service life 3 years
Compatible electrode IBT Electrodes
Bluetooth FCC, IC, CE, RoHS, and Bluetooth®
4.0 Certified ISM 2.4GHz module
Hands Wrists Elbows
SensorHand Speed bebionic small
MC ProWrist (with 4 or
6 band coaxial plug)
DynamicArm
MyoHand VariPlus Speed i-limb access
ProHand i-limb ultra
ProETD i-limb ultra revolution
Ottobock OB 10S17 with
Myorotronic
Steeper MyoHand i-limb quantum
bebionic3
Voltage Output 7.4V DC
Capacity Range * 550 mAh - 2200 mAh
Current Output Up to 7A
Temperature range (use) 0
o
C to +49
o
C (32
o
F to 120
o
F)
Temperature range
(transport and storage)
0
o
C to +49
o
C (32
o
F to 120
o
F)
Included in the Package
• Element signal processing box
• IBT Electrodes
• Molding dummies for IBT Electrodes
• Molding dummy for signal processing box (if requested)
• USB Thumb drive containing Element desktop software
• Bluetooth Adapter
• FlexCell batteries (if ordered with Element)
What You’ll Need
• PC
• FlexCell batteries (if not ordered with Element)
• Terminal device
• Coaxial plug (if not using a wrist or elbow)
• Lamination collar parts
Terminal Devices That Have Been Tested For Compatibility With Element
For FlexCell
* Capacity range is dependent on how many FlexCell batteries are installed.
BEFORE YOU BEGIN
Specifications Installation
3 4
