WARNING: Ensuring
Adequate Ventilation
Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not
blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting
unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by
screws, at a minimum distance of 50mm from the bottom of the hob. Follow the requirements
below.
There are ventilation holes around outside of the hob. YOU MUST
ensure these holes are not blocked by the worktop when you put the hob
into position.
A(mm) B(mm) C(mm) D E
760 50 min. 20 min. Air intake Air exit 5mm
