Infinity 1210a - Reference 1211 A Electrical Parts List Addendum

Reference 1211a Electrical Parts List Addendum
The following chart below represents the only electrical parts
differences in 1210a and 1211a models:
MODEL PART NAME PART NUMBER SPEC DESIGNATOR
REF 1210a RESISTOR RES-00-00756 1/5WF 820 OHM R116
1
REF 1211a RESISTOR RES-00-00474 1/5WF 240 OHM R116
REF 1210a RESISTOR RES-00-00482 1/5WF 2K OHM R117
2
REF 1211a RESISTOR RES-00-00577 1/5WF 750 OHM R117
REF 1210a RESISTOR RES-00-00575 1/5WF 7.5K OHM R118
3
REF 1211a RESISTOR RES-00-00402 1/5WF 10K OHM R118
REF 1210a POWER TERMINAL TER-00-00163 (3P) DST0010-00 TER1
3
REF 1211a
POWER TERMINAL
TER-00-00278 (3P) DK-03B04-AG-5-UP TER1
REF 1210a SPEAKER TERMINAL TER-00-00034 (4P) TM0009-01 TER2
4
REF 1211a
SPEAKER TERMINAL
TER-00-00276 (4P) DK-04A04-AG-5-UP TER2
20
Power Amplifier
Reference 1210a/1211a
