Infinity Classia Series User Manual

Part Number Description Qt
y
Reference Desi
g
nato
r
MAIN/POWER SUPPLY PCB
175-1d02v01-e Connector 2PIN PITCH=3.96mm(RoHS) 1
P112,
175-1d05v01-e Connector 5PIN 3.96mm (RoHS) 1
P113,
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 1
INPUT/PREAMP PCB
Resistors
118-08050000J-E SMD Resistor 0805 1/10W 0Ω±5%LF 2
JP1,JP3,
118-08051000F-E SMD Resistor 0805 1/10W 100 ±1% LF 6
R314,R315,R125,R151,R152,R215,
118-08051001F-E SMD Resistor 0805 1/10W 1K ±1% LF 2
R140,R194,
118-08051001J-E SMD Resistor 0805 1/10W 1K ±5% LF 5
R400,R401,R405,R406,R410,
118-08051002F-E SMD Resistor 10.0K 0805 1/10W 1%(RoHS) 16
R330,R331,R111,R118,R122,R124,R133,R136,R146,R14
9
, R308,R130,R131,R132,R199,R263,
118-08051002J-E SMD Resistor 0805 1/10W 10KΩ ±5%LF 2
R402,R403,
118-08051004J-E SMD Resistor 1M 0805 1/10W 5%(RoHS) 1
R145,
118-08051201J-E SMD Resistor 1.2K 0805 1/10W 5%(RoHS) 1
R409,
118-08051500F-E SMD Resistor 0805 150ohm 1% (RoHS) 1
R139,
118-08051504J-E SMD Resistor 1.5M 0805 1/10W 5%(RoHS) 1
R142,
118-08051693F-E SMD Resistor169K 0805 1/10W 1%(RoHS) 1
R195,
118-08051802J-E SMD Resistor 18K 0805 1/10W 5%(RoHS) 1
R147,
118-08052001F-E SMD Resistor 0.1W 1% 2K (RoHS) 1
R202,
118-08052002F-E SMD Resistor 0805 20.0K 1% (RoHS) 1
R200,
118-08052052F-E SMD Resistor20.5K 0805 1/10W 1%(RoHS) 2
R197,R198,
118-08052200J-E SMD Resistor 0805 1/10W 220Ω 5%(RoHS) 11
R411,R332,R333,R119,R120,R154A,R155A,R159A,R160
A
, R334,R335,
118-08052202F-E SMD Resistor 0805 1/10W 22K±1%(RoHS) 2
R141,R148,
118-08052202J-E SMD Resistor 0805 1/10W 22KΩ ±5%LF 1
R404,
118-08052212F-E SMD Resistor 0805 22.1K 1% (RoHS) 3
R193,R204,R206,
118-08052262F-E SMD Resistor 0805 22.6K 1% (RoHS) 4
R209,R296,R297,R298,
118-08052402F-E SMD Resistor 24K 0805 1% (RoHS) 1
R117,
118-08053301J-E SMD Resistor 0805 1/10W 3.3K ±5%(RoHS) 1
R407,
118-08053401F-E SMD Resistor 3.4K 0805 1/10W 1%(RoHS) 1
R128,
118-08053923F-E SMD Resistor392K 0805 1/10W 1%(RoHS) 1
R208,
118-08054301F-E SMD Resistor 0.1W 1% 4.3K(RoHS) 1
R254,
118-08054320F-E SMD Resistor432Ω 0805 1/10W 1%(RoHS) 1
R265,
118-08054421F-E SMD Resistor 0.1W 1% 4.42K(RoHS) 2
R205,R207,
118-08054701J-E SMD Resistor 0805 1/10W 4.7K ±5%LF 1
R144,
118-08054702J-E SMD Resistor 47K 0805 1/10W 5%RoHS 9
R109,R114,R115,R116,R121,R137,R138,R219,R412
,
118-08054703J-E SMD Resistor 470K 0805 1/10W 5%(RoHS) 1
R143,
118-08054R70J-E SMD Resistor 4R7 0805 1/10W 5%(RoHS) 1
R153,
118-08055101F-E SMD Resistor 5.1K 0805 1/10W 1%(RoHS) 8
R316,R317,R318,R319,R320,R321,R322,R323
,
118-08056801F-E SMD Resistor 6.8K 0805 1/10W 1%(RoHS) 6
R300,R301,R110,R112,R113,R123,
118-08056812F-E SMD Resistor 0805 68.1K 1% (RoHS) 1
R135,
118-08058061F-E SMD Resistor8.06K 0805 1/10W 1%(RoHS) 1
R134,
115-H203A106-E Variable Resistor A20K (RoHS) LEVEL 1
VR1,
115-H503B405-E Variable Resistor B50K (RoHS) CROSSOVER 1
VR2,
Ca
p
acitor
s
141-B0101J50-E CAP CERAMIC/CHIP 100PF 50V CHJNPO 0805 RoHS 6
C318,C319,C331,C332,C110B,C148,
141-B0221J50-E SMD Cer capacitor 220P 50V NPO 0805(RoHS) 3
C304,C305,C212,
141-B0470J50-E SMD Cer capacitor 47pF 0805 NPO 50V(RoHS) 1
C128,
141-B0680J50-E SMD Cer capacitor 68pF 0805 NPO 50VRoHS 1
C127,
141-B5104Z50-E Cer capacitor CAP SMD 0805 Y5V0.1uF +80/-20% 50V L
F
19
C320,C322,C112,C114,C116,C118,C124,C125,C130,C23
2
, C233,C153,C154,C184,C185,C206,C205,C144,C145,
141-B7102J50-E SMD Cer capacitor 0805 X7R 1nF 50V5% (RoHS) 2
C181,C182,
141-B7272K50-E SMD Cer capacitor0805 2700PF 50V X7R(RoHS) 1
C110,
141-B7332J50-E SMD Cer capacitor 0805 X7R 3300pF 5%(RoHS) 2
C120,C317,
141-B7472J50-E SMD capacitor 0805 X7R 4700PF 5% 50V(RoHS) 1
C110A,
129-A223J633-E Capacitor 0.022U 63V ±5% MSC (RoHS) 1
C150,
129-A224J633-E Capacitor 0.22uF 63V ±5% MSC(RoHS) 2
C121,C122,
129-A333J633-E Capacitor 0.033U 63V MSC (RoHS) 2
C209,C218,
129-A473J633-E Capacitor 0.047U 63V ±5% MSC (RoHS) 1
C149,
129-A683J633-E Capacitor 0.068U 63V ±5% MSC RoHS 2
C201,C213,
135-3106M25-E Capacitor 10uF 25V ±20% (RoHA) 10
C310,C311,C109,C111,C123,C126,C129,C133,C134,C141
135-3107M16-E Capacitor 100uF 16V ±20% (RoHS) 16
C152,C159,C160,C327,C328,C155,C156,C113,C115,C11
7
, C119,C132,C157,C158,C329,C330,
135-3226M25-E Capacitor 85℃ 22uF ±20%25V LF 2
C312,C151,
