Part Number Description Qt
y
Reference Desi
g
nato
r
INPUT/PREAMP PCB
139-3227M16-E Capacitor 220uF 16V±20% (RoHS) 1
C131,
Semiconductor
s
190-16TL072DTS-E I.C. TL072N @6.5 (RoHS) DUAL OP-AMP 4
U109,U101,U103,U108,
190-16TL074CDS-E I.C TL074CN ST (RoHS) QUAD OP-AMP 2
U102,U106,
192-027C1815GRS-E SMT Transistor MMBT1815 SOT-23(RoHS) 5
Q402,Q403,Q101,Q102,Q103,
192-998A1015GRS-E SMD Transistor MMBT1015 CJ SOT-23(RoHS) 2
Q400,Q401,
197-0S4148WSP-E SMD Diode LL4148WSP 0805SHAWELL 10
D400,D108,D109,D110,D207,D208,D303,D304,D112,D11
3
199-6200082D-E Diode 8.2V BZT52-C8V2SSOD-323(RoHS) 1
D130,
192-153MPF102-E Transistor FAIRCHILD MPF102 (RoHS)TO-92 1
Q107,
Miscellaneous
162-10169003-E Wire 160mm AWG28 (RoHS) 1
P105,
162-8008D001-E Wire 80mm 4pin P=2.0mm(RoHS) 1
P1,
162-A013D001-E WIRE UL1007#28 130mm (RoHS) 1
P104,
174-0RCA313G-E RCA Jack RCA-313G (RoHS) 1
JK1,
175-1C02V01-E Connector 2PIN PITCH=2.5mm (RoHS) 1
P106,
180-T000TS81-E TACT Switch L101 T2 T8019L-SNQ-E-H+U RoHS 3
SW103,SW104,SW105,
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 1
BK2,
RABOS PCB
Resistors
115-H103A203-E
Variable Resistor RV16A01-20-15K-A10K-3E (RoHS)
LEVEL, WIDTH
2 R158,R177
115-H103C201-E Variable Resistor RV16A01-20-15K-C10K-3E
(
RoHS
)
FR 1
R163
110-16105J26-E Resistor 1M 1/6W ±5% CF 26mm (RoHS) 1
R181,
110-16106J26-E Resistor 10M 1/6W ±5% CF 26mm (RoHS) 1
R186,
116-161000F26-E Resistor 100Ω 1/6W ±1% MF26mm (RoHS) 1
R154,
116-161001F26-E Resistor 1K 1/6W ±1% MF26mm (RoHS) 3
R180,R187,R252,
116-161002F26-E Resistor 10K 1/6W ±1% MF 26mm (RoHS) 7
R159,R160,R171,R173,R178,R192,R166,
116-161103F26-E Resistor 110K ±1% MF 1/6W26mm (RoHS) 1
R174,
116-161502F26-E Resistor 15.0K 1/6W ±1% MF26mm (RoHS) 2
R162,R168,
116-161652F26-E Resistor 16.5K 1/6W ±1% MF26mm (RoHS) 1
R188,
116-162051F26-E Resistor 2.05K 1/6W MF 26mm (RoHS) 1
R253,
116-162211F26-E Resistor 2.21K 1/6W ±1% MF26mm (RoHS) 1
R172,
116-162671F26-E Resistor 2.67K 1/6W ±1% MF26mm (RoHS) 1
R155,
116-163161F26-E Resistor3.16K 1/6W±1% MF 26mm (RoHS) 1
R251,
116-163400F26-E Resistor 340Ω 1/6W ±1% MF26mm (RoHS) 2
R164,R169,
116-163571F26-E Resistor 3.57K 1/6W 1% MF 26mm (RoHS) 1
R157,
116-165400F26-E Resistor540Ω 1/6W MF 26mm (RoHS) 1
R175
116-166041F26-E Resistor 6.04K 1/6W ±1% MF 26mm (RoHS) 2
R165,R170,
116-166341F26-E Resistor 6.34K±1%MF 1/6W 1
R189,
116-166800F26-E Resistor 680Ω 1/6W ±1% MF26mm (RoH 1
R176,
116-168250F26-E Resistor 825Ω 1/6W ±1% MF26mm (RoHS) 2
R161,R167,
116-169092F26-E Resistor 90.9K 1/6W MF 26mm (RoHS) 1
R190,
116-169311F26-E Resistor 9.31K 1/6W ±1% MF26mm (RoHS) 1
R179,
Ca
p
acitor
s
129-A104J633-E Capacitor 0.1U 63V ±5% MSC (RoHS) 3
C137,C138,C139,
129-A683J633-E Capacitor 0.068U 63V ±5% MSC RoHS 2
C142,C143,
130-3F104Z503-E Capacitor 0.1U 50V +80/-20% (RoHS) 4
C144,C145,C146,C147,
Semiconductor
s
190-16TL072N-E I.C. TL072N @6.5 (RoHS) DUAL OP-AMP 1
U105
190-16TL074CN-E I.C TL074CN ST (RoHS) QUAD OP-AMP 1
U104
Miscellaneous
175-9C08V01-E Connector 8PIN PITCH=2.5mm (RoHS) 1
P104
28
