Part Number Description Qt
y
Reference Desi
g
nato
r
WIRELESS RECEIVER PCB
Resistors
118-08050000J-E SMD Resistor 0805 1/10W 0Ω±5%LF 8
R21,R27,R28,R29,R30,R36,R37,R22,
118-08051002J-E SMD Resistor 0805 1/10W 10KΩ ±5%LF 3
R26,R12,R13,
118-08051200F-E SMD Resistor 120Ω 0805 1% RoHS 1
R503,
118-08052002J-E SMD Resistor 20K 0805 1/10W 5%(RoHS) 15
R04,R05,R06,R07,R08,R09,R10,R11,R14,R15,R16,R17,
R
18, R19,R20,
118-08052400F-E SMD Resistor 240Ω0805 1% ROHS 1
R504,
118-08052703J-E SMD Resistor 270K 0805 5% (RoHS) 1
R502,
118-08053303J-E SMD Resistor 330K 0805 5% (RoHS) 1
R501,
118-08054701J-E SMD Resistor 0805 1/10W 4.7K ±5%LF 1
R38,
118-08054702J-E SMD Resistor 47K 0805 1/10W 5%(RoHS) 1
R03,
118-08054R70J-E SMD Resistor 4R7 0805 1/10W 5%(RoHS) 2
R01,R02,
118-080556R0J-E SMD Resistor 0805 56Ω 1/10W 5%(RoHS) 1
L01,
118-08056200J-E SMD Resistor 0805 620Ω ±5% (RoHS) 2
R39,R40,
116-1410R0J5VX-E Resistor 10Ω 1/4W ±5% (RoHS) 1
R505,
Ca
p
acitor
s
141-B7102J50-E SMD Cer Capacitor 0805 X7R 1nF 50V5% (RoHS) 1
C06,
141-B7103K50-E SMD Cer Capacitor 0.01U 50V X7R 0805(RoHS) 2
C03,C505,
141-B7104K50-E Cer Capacitor CAP SMD 0805 X7R0.1uF ±10% 50V LF/R 10
C02,C05,C08,C09,C10,C14,C16,C504,C507,C509
,
141-B7332J50-E SMD Cer Capacitor 0805 X7R 3300pF 5%(RoHS) 2
C20,C21,
142-AV107M16H-E SMD capacitor 100UF 16V φ6.3*5.4mm (RoHS) 1
C11,
142-SV105M50H-E SMD capacitor 1uF 50V 4.3*4.3mm(RoHS) 2
C15,C17,
142-SV106M16H-E SMD capacitor 10U 16V (RoHS) 3
C12,C13,C18,
130-2B104KA03-E Cer capacitor 0.1uf 100V 10% (RoHS) 1
C503,
135-3476M100-E Capacitor 47uF 100V±20% 10*16 5mm (RoHS) 1
C501,
135-3477M16-E Capacitor 85℃ 470uF ±20%16V LF 4
C01,C04,C511,C506,
Semiconductor
s
190-145008MMS-E
SMD IC LM5008MM/NOPB(NATIONAL)(RoHS) High
Volta
g
e
(
100V
)
Ste
p
Down Switchin
g
Re
g
ulato
r
1 U501,
190-19HCT165S-E
SMD IC 74HC/HCT165(RoHS)PHILIPS 8-bit parallel
-
in/serial-out shift re
g
ister
2 U02,U03,
190-99CS4340KS-E
IC CS4340-KS 16Pin SoIC(RoHS) 24-Bit, 96 kHz Stereo DAC
1 U04,
190-99IMP809S-E
SMD IC IMP809SEUR-T
(
IMP
)(
RoHS
)
RESE
T
1
U01,
197-63S110-E Diode S100 100V 1A SMAD0-214AC(RoHS) 1
D501,
051-WH4927-E Wireless HI-FI Audio RX ModuleWH4927 (RoHS) 1
MD01
Miscellaneous
175-1B04V01A-E Connector 4PIN PITCH2.0mm (RoHS) 1
P1,
175-1C02V01-E Connector 2PIN PITCH=2.5mm (RoHS) 1
P501,
175-9B06V03-E Connector 6Pin PITCH=2.0mm(RoHS) 1
SW01,
175-9Y25V2201-E PIN HEADER 25PH=1.27mm(RoHS) 1
333-EVA-05425-0BAE Gasket EVA 13*10*3MM CONTROL 2.4G (RoHS) 2
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 2
BK01,BK02,
162-5009D006-E Wire 90mm P=2.0mm(RoHS) 1
180-SS14H03GT-E SLIDE SW SS14H03GT-GP
(
RoHS
)
Wireless ID Code 1,
2
1
SW01,
121-COMM220M-E SMD Inductor22UH±20%YC5D18T*220MS(RoHS) 1
L502,
121-COMM221M-E SMD Inductor220UH±20% YC8D43T*221MS(RoHS) 1
L501,
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
Resistors
118-12061001F-E SMD Resistor 1K 1206 1% (RoHS) 1
R2,
118-12061002F-E SMD Resistor 10K 1206 1% (RoHS) 1
R25,
118-12061002J-E SMD Resistor 10.0K 1206 5% (RoHS) 5
R29,R30,R30B,R7,R9,
118-120610R0J-E SMD Resistor 10.0Ω 1206 5% (RoHS) 4
R20,R20B,R22,R23,
118-12062002F-E SMD Resistor 20K 1206 1% (RoHS) 1
R26,
118-12062201J-E SMD Resistor 2.20K 1206 5% (RoHS) 18
R13,R16,R31,R33,R34,R35,R36,R37,R38,R39,R40,R41,
R
42, R43,R44,R45,R46,R32,
118-12062204J-E SMD Resistor 2.20M 1206 5% (RoHS) 1
R4,
118-12062211F-E SMD Resistor 2.21K 1206 1% (RoHS) 1
R6,
118-12062550F-E SMD Resistor 1206 255Ω 1% (RoHS) 1
R24,
118-12062701J-E SMD Resistor 2.70K 1206 5% (RoHS) 1
R10,
29
PSW310W subwoofer Classia Series
