Part Number Description Qt
Reference Desi
nato
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
118-12063301J-E SMD Resistor 3.30K 1206 5% (RoHS) 4
R14,R15,R27,R28,
118-12063321F-E SMD Resistor 3.32K 1206 1% (RoHS) 1
R1,
118-12063922F-E SMD Resistor 1206 39.2K±1% (RoHS) 1
R3,
118-12064700J-E SMD Resistor 470Ω 1206 5% (RoHS) 3
R8,R11,R21,
118-12064701J-E SMD Resistor 4.7K 5% 1206(RoHS) 1
R12,
118-12064751F-E SMD Resistor 4.75K 1206 1% (RoHS) 1
R5,
112-10180J00-E Fuse resistor FMF 1W 18Ω 5%(RoHS) 1 R47
Ca
acitor
141-C0101K50-E SMD Cer capacitor 100pF 50V 10%1206 NP0 (RoHS) 1
C4,
141-C0220K50-E SMD Cer capacitor 22pF 50V 10% 1206SMT NPO
RoHS 1
C5,
141-C0561K50-E SMD Cer capacitor 560pF 50V 10%1206 NPO (RoHS) 1
C6,
141-C5104M50-E SMD Cer capacitor 1206 Y5V 0.1uF50V ±20% (RoHS) 8
C2,C3,C7,C8,C9,C10,C11,C15,
141-C7103K50-E SMD Cer capacitor 10nF 50V 1%1206 X7R (RoHS) 1
C13,
141-D7104KB5-E SMD Cer capacitor 0.1uF 250V 10%1210 X7R (RoHS) 2
C18,C19,
128-E106MA01-SE Capacitor 10uF 100V 20%(RoHS) 2
C16,C17,
129-A104JA03-E Capacitor 0.1U 100V ±5% MSC (RoHS) 2
C12B,C14,
130-SL681KB03-E Capacitor SL 680PF 200V (RoHS) 1 C21
132-104KB50-E Capacitor 0.1U ±10% 250V (RoHS) 1
C20,
132-105KB50-E Capacitor 1uF 250V ±10% (RoHS) 1
C40,
Semiconductor
192-1582N5401-E Transistor FSC 2N5401 AI-PNP 350V500mA TO-92
RoH 1
Q6B,
192-232IRF9640-E FET IRF9640 IR P-CH TO220(RoHS) 2
Q10,Q10B,
192-233F640N-E Transistor IRF640N INTERNATIONAL(RoHS) 1
Q11,
190-16tl072dts-e
SMD I.C. TL072CDT SGS THOMSON(RoHS) DUAL OP-AMP
1
IC1,
192-09124126qs-e SMD Transistor 2SC2412K-T146Q/RROHM (RoHS) 2
Q1,Q4,
192-09139066rs-e SMD Transistor 2SC3906K-T146R ROHM(RoHS) 2
Q2,Q8,
192-091SC4672-E Transistor 2SC4672(MPT3) ROHM(RoHS) 1
Q5B,
192-09210376qs-e SMD Transistor 2SA1037K-T146Q/RROHM (RoHS) 2
Q7,Q9,
192-09215146rs-e SMD Transistor 2SA1514K-T146R ROHM(RoHS) 1
Q3,
197-03rls4148s-e *SMD diode RLS4148-TE11 ROHM(RoHS) 8
D1,D2,D3,D4,D5,D5B,D6,D20,
199-15000563S-E SMD ZENER 5.6V 5% PHILIPSBZX84-C5V6(RoHS) 2
Z1,Z2,
199-1500120s-e SMD ZENER 12V 5% PHILIPSBZX84-C12 (RoHS) 4
Z3,Z4,Z5,Z6,
Miscellaneous
122-13151K0190-E CHOKE SA-500-280(PT1601B*151MAA) (RoHS) 1
L1,
122-14300K4-E Ferrite core LD1215*300KU±10% RoHS 1
L2,
175-9F02H02-E Connector 2PIN PITCH=2.54mm(RoHS) 1
HDR3,
175-9F03H020-E Connector 3PIN PITCH=2.54mm(RoHS) 2
HDR1,HDR2,
359-FIB-00125-E Gasket 10*5*0.5T (RoHS) 2
2
EMI/FUSE PCB
154-K31505T0-E Fuse 3.15A 250V 30mm UL/CSA/PSE (RoHS) 1
155-630R345B-E Fuse holder UL/CSA ψ6*30mm R3-45B (RoHS) 1
122-14103M4200-E Inductor RT251510*103N 10mH (RoHS) 1
L02
122-14501M0650-E Inductor 0.5mH ψ0.65 (RoHS) 1
L01
130-3F102MB50-E Capacitor Y1 1NF 20%250V (RoHS) 2
C03,C04
132-334KB70-E Capacitor 0.33U 275V +/-10% (RoHS) 1
C02
132-334KB74-E Capacitor 0.33uF 275V +/-10% LS=15mm (RoHS) 1
C01
162-10099003-E Wire 90mm20AWG (RoHS) 1
162-10100007-E Wire 100mm20AWG (RoHS) 1
MISCELLANEOUS/MECHANICAL
195-443391EV-E
Bipolar LED (Cabinet) 339-1EVGW(339-1SURSYGW/S350-A3
1
D401
128-C117JA01-E electrol
tic CAP 110uf 100V 1
Soldered to Woofer terminals
123-11K4DRH-E Ferrite core K4DRH 16*28.5*9 (RoHS) 3
123-11RH633215-E Ferrite coreK5ARH 6.35*3.2*15.8(RoHS) 1
150-R1107011A-E Power Transformer TT0930505260120V(RoHS) 1
152-U602015A-E Power cord SVTFT-2 6FT#187 BLK (RoHS) 1
162-10090003-E WIRE 90mm20AWG (RoHS) 1
162-5016D001-E WIRE 24# 160mm (RoHS) 1
162-5018D007-E WIRE 180mm 2pin Red/BLK22AWG(RoHS) 1
166-5070A4BD-E Speaker wire #18 UL1015#205*0.5t BLK/#250*0.8t Red
1
PSW310W subwoofer Classia Series
