Infinity ENTRA User Manual

Entra Subwoofer
12
Electrical Parts List
Part Description Designator Quantity
No.
PRE AMP PCB ASSEMBLY
Resistors
020-100498-120 CARBON FILM RESISTOR 1K 1/8W J R107,123,138 3
020-100598-120 CARBON FILM RESISTOR 10K 1/8W J R136,127,121, 6
135,124,125
020-100698-120 CARBON FILM RESISTOR 100K 1/8W J R133 1
020-110598-120 CARBON FILM RESISTOR 11K 1/8W J R122 1
020-150598-120 CARBON FILM RESISTOR 15K 1/8W J R118 1
020-180698-120 CARBON FILM RESISTOR 180K 1/8W J R128 1
020-220698-120 CARBON FILM RESISTOR 220K 1/8W J R126,129 2
020-330498-120 CARBON FILM RESISTOR 3K3 1/8W J R132,134 2
020-750498-120 CARBON FILM RESISTOR 7K5 1/8W J R110,112 2
021-100401-120 M.O.F. RESISTOR 1K 1W J MO-100 R101,102 2
021-100598-100 METAL FILM RESISTOR 10K 1/8W F R109 1
021-154598-100 METAL FILM RESISTOR 15K4 1/8W F (MF) R137 1
021-169598-100 METAL FILM RESISTOR 16K9 1/8W F (MF) R120 1
021-200698-100 METAL FILM RESISTOR 200K 1/8W F R103,104,105,106 4
021-215598-100 METAL FILM RESISTOR 21K5 1/8W F (MF) R111 1
021-280498-100 METAL FILM RESISTOR 2K8 1/8W F R130 1
021-442598-100 METAL FILM RESISTOR 44K2 1/8W F R131 1
021-511498-100 METAL FILM RESISTOR 5K11 1/8W F R116,117 2
Capacitors
030-100247-300 CERAMIC CAPACITOR 0u1/50V Z P:5 C110,109,121,122, 6
118,119
030-220223-300 CERAMIC CAPACITOR 220P/50V K P:5 C105,106,107 3
032-100243-301 PE CAPACITOR 0u1/63V J P:5m/m C114 1
032-220353-300 PE CAPACITOR 0u22/63V J P:5m/m C104,108 2
032-470353-303 PE CAPACITOR 0u47/63V J P:5m/m C113,125,123 3
034-100525-300 ELEC. CAPACITOR 10uF/25V M (R) P:5 C102,103,120 3
034-100614-300 ELEC. CAPACITOR 100uF/16V M (R)2.5 C127,128 2
034-100715-200 ELEC. CAPACITOR PC 1000uF/16V M (R)P:5 C124 1
034-220515-300 ELEC. CAPACITOR PC 22uF/16V M (R) P:5 C111 1
Semiconductors
050-414802-100 DIODE 1N4148 D101,102,103, 5
104,109
050-505200-000 LED P/N:UDC-5052W LED D110 1
051-101501-000 TRANSISTOR PNP 2SA1015GR TO-92 Q102,103 2
051-181502-000 TRANSISTOR NPN 2SC1815GR TO-92 Q101 1
053-007200-000 IC TL072 CP DIP DUAL OP-AMP IC102 1
053-007400-000 IC TL074CN QUAD OP-AMP IC101 1
053-455801-000 I.C PC BA4558 (ROHM) DUAL OP-AMP IC103 1
