Infinity ENTRA - Page 13

Entra Subwoofer
13
Electrical Parts List
Part Description Designator Quantity
No.
Miscellaneous
072-010058-000 RCA JACK 2P P/N:052000W1G(Red,White) JK101 1
074-030002-000 TOGGLE SW P/N L101 SW101 1
083-031605-000 CONNECTOR LEAD WIRE #26 L:60mm #18 L:70mm CN1 1
083-052618-000 CONNECTOR LEAD WIRE EH2.5-7P+SCN2.5P+7 CN101 1
LEAD WIRE
026-200595-263 VR P/N:R1210G-2A1-B20Kx2 10% VR101 1
026-200595-264 VR P/N:R1210N-2A1-B20K 10% VR102 1
MAIN AMP ASSEMBLY
Resistors
020-100398-120 CARBON RESISTOR 100R 1/8W J R511,714,719 3
020-100498-120 CARBON RESISTOR 1K 1/8W J R506,721,507,702 4
020-100598-120 CARBON RESISTOR 10K 1/8W J R503,610,504,510, 7
512,601,606
020-100698-120 CARBON RESISTOR 100K 1/8W J R712,725,731 3
020-150498-120 CARBON RESISTOR 1K5 1/8W J R713,718,721 3
020-150598-120 CARBON RESISTOR 15K 1/8W J R607,709,711 3
020-220498-120 CARBON RESISTOR 2K2 1/8W J R710,742 2
020-220598-120 CARBON RESISTOR 22K 1/8W J R502,508,701,703 4
020-220698-120 CARBON RESISTOR 220K 1/8W J R603 1
020-270398-120 CARBON RESISTOR 270R 1/8W J R715,717 2
020-270698-120 CARBON RESISTOR 270K 1/8W J R611 1
020-330297-120 CARBON RESISTOR 33R 1/4W J R723,724 2
020-390598-120 CARBON RESISTOR 6 39K 1/8W J R716 1
020-470498-120 CARBON RESISTOR 4K7 1/8W J R602 1
021-470597-120 M.O.F. RESISTOR 47K 1/4W J R728 1
020-470598-120 CARBON RESISTOR 47K 1/8W J R505,604,605 3
020-560398-120 CARBON RESISTOR 560R 1/8W J R743 1
021-100003-020 M. O. F. RESISTOR 0R1 3WS J R734,735 2
021-100201-121 M. O. F. RESISTOR 10R 1W J MO R608,609 2
021-100397-120 M. O. F. RESISTOR 100R 1/4W J R726,730 2
021-100401-120 M. O. F. RESISTOR 1K 1W J R739 1
021-100496-120 M. O. F. RESISTOR 1K 1/2W R727,729 2
021-330498-120 M. O. F. RESISTOR 3K3 1/8W J R720 1
021-499698-100 METAL FILM RESISTOR 499K 1/8W F R513,509 2
021-680296-120 M. O. F. RESISTOR 68R 1/2W J R732,733 2
Capacitors
030-100264-300 CERAMIC CAPACITOR 0u1/100V K NPO C718,707,708,719 4
030-220223-300 CERAMIC CAPACITOR 220P/50V K P:5 C703,702,717,716 4
030-220244-261 CERAMIC CAPACITOR 22pF/50V J NPO C712,713 2
030-470344-200 CERAMIC CAPACITOR PC 470pF/50V 10 C715,714,711,710 4
