Entra Subwoofer
14
Electrical Parts List (Cont.)
Part Description Designator Quantity
No.
032-100393-300 PE CAPACITOR 0u1/63V J P:5 C606,607,601,709 4
034-100515-301 ELEC. CAPACITOR PC 10uF/16V M (R)0511 C701,723 2
034-100615-301 ELEC. CAPACITOR 100uF/16V M (R)0611 C605 1
034-100695-300 ELEC. CAPACITOR 100uF/63V M (R)1012 C720,721 2
034-470415-300 ELEC. CAPACITOR 4u7/50V M (R)0511 P: C501,603 2
034-470515-000 ELEC. CAPACITOR 47uF/16V M (R)0511 C502,604,704 3
035-220143-100 PE CAPACITOR FE-M 0u0022/63V J P:5m/m C608 1
035-220243-100 PE CAPACITOR FE-M 0u022/63V J P:5m/m C503 1
Semiconductors
050-003000-100 ZENER DIODE 30V HZ-30-2 05000881 D807 1
050-400201-100 DIODE 1N4002 100V/1A TAPING D710,711,601, 6
717, 712, 806
050-414802-100 DIODE 1N4148 D501,713,715,716, 7
714,708,709
053-123700-100 IC PC UPC 1237HA LIMITER IC601 1
053-455801-000 I.C PC BA4558 (ROHM) OP-AMP IC501,701 2
051-003100-000 TRANSISTOR TIP 31C TO-220 Q707 1
051-003200-000 TRANSISTOR TIP 32C TO-220 Q708 1
051-046900-000 TRANSISTOR 4 BF469 Q704 1
051-047000-000 TRANSISTOR BF470 Q703 1
051-066900-000 TRANSISTOR 1 2SD669A (C class) Q711 1
051-138600-000 TRANSISTOR 2SA 1386(SANKEN) TO-3P Q710 1
051-181500-000 TRANSISTOR PC 2SC1815GR Q501,502,602,603 4
051-351900-000 TRANSISTOR 2SC 3519(SANKEN) TO-3P Q709 1
051-540100-000 TRANSISTOR 2N5401 Q702,706,601 3
051-555100-000 TRANSISTOR 2N5551 TO-92 Q701,705 2
Miscellaneous
061-700011-101 SLICON RUBBER PCS P/N:1877 110x30mm t=0.19mm 1
072-040007-000 7P WAFER SWA101 BC501 JS-1001-07 1
072-040039-000 TERMINAL (PCB) PC205 (t=0.8m/m)T205MA J602 1
072-040041-000 TERMINAL(PCB) T250MA (P/N 0635R-BL2) J601 1
072-040206-000 CONNECTOR P/N:3PIN JS-1001-4 P:2.5 CON802 1
073-014005-600 BRACKET(LEFT SIDE) PCS 72x19m/m t=1mm 1
073-014006-600 BRACKET(RIGHT SIDE) PCS 72x19m/m t=1mm 1
074-300004-000 RELAY 48VDC P/N PCE-148D1H RLY601 1
083-022547-000 CONNECTOR WIRE #18 VH3.96+SCN2.5 CN302 1
025-050001-000 VARISTOR TSA-104 TH601 1
