Entra Subwoofer
15
Electrical Parts List (Cont.)
Part Description Designator Quantity
No.
POWER SUPPLY PCB ASS’Y
Resistors
020-820497-120 CARBON RESISTOR 8K2 1/4W J R301,304 2
021-470301-120 MO RESISTOR 470R 1W J MB TYPE MO-100 R303,302 2
Capacitors
030-100264-300 CERAMIC CAPACITOR 0u1/100V K NPO TAPING C2,3 2
030-100295-201 UL SAFETY CAPACITOR YS-SC103Z2 10000pF/400V C309 1
034-220515-300 ELEC. CAPACITOR PC,308 22uF/16V M (R)0511 C307 1
034-220615-301 ELEC.CAPACITOR 220uF/16V M (R)0611 P:5 C305,306 2
034-470763-301 ELEC.CAPACITOR 4700uF/63V M (R) 25*40 C303,304 2
Semiconductors
050-001500-000 DIODE 15V 1/2W HZ15-3 ZD301,302 2
051-118900-100 TRANSISTOR 2SD882P(TO-220) Q301 1
051-677000-000 TRANSISTOR 2SB772 (TO-220) Q302 1
Miscellaneous
052-602000-000 RECTIFY DIODE KBU8D(SUB-100W) 8A/200V BD2 1
072-040032-000 WAFER 2 P:3.96 3P MALE VH CN30 1
073-032027-000 HEAT SINK PCS 40x24x2.0m/m 1
083-021805-000 LEAD WIRE #22 GND WIRE L:80mm 5TT+5TT 1
083-022548-000 LEAD WIRE #18 UL1015 PCS T187(t0.8)+ B1811T0P-2 2
083-031603-000 4Px120mm CONNECTOR 1 LEAD WIRE #22 +5TT CN30 1
091-000130-000 FUSE HOLDER PCS P/N:CQ-203SP 2
093-105203-300 FUSE:UL GSL(2AG) FUSE:3A,250V,5*20mm F301 1
MISCELLANEOUS
005-009885-000 GASKET 97.5x85x36cm 1
005-033420-000 STYROFOAM 335.0x191.0x65.0mm 40
008-068701-000 GASKET SM-55 GASKET 860.0x5.0 t=2.0mm 2
042-010042-000 TRANSFORMER P/N:PT-1739 1
061-020000-000 KNOB ABS HTS-10/20 p20x15m/m UL94V-0 BLK 2
061-314002-000 CORD BUSHING P/N SB4F-2 1
061-800000-000 TRANSISTOR COVER P/N:TW-1 2
062-050400-000 PUSH TERMINAL 4P JK102A,JK102B P/N E405 2
062-261313-000 BUCKET(HI PS 94VO)304.8x177.8x124.2m/m BLK 1
063-062512-000 PLATE 304.8x177.8 t=2.5mm (SPCC) 1
066-120300-900 CABLE TIE PCCV-120S 3
070-000030-410 SCREW TRANSFORMERx4,HEAT SINKx6 M4;4x10m/m BLK 10
070-040010-210 SCREW PC TRAN.x5,TH601x1,GROND WIREx1 PMS M3x10m/m BLK 7
070-400010-206 SCREW PCB VS BRACKETx4,BRACKET VS HEAT SINKx23x6m/m BLK 6
070-400010-212 SCREW 3x12m/m BLK 1
070-400010-812 SCREW RCA JACKx1 PTS-4 3x12 BLK 1
