MSW-1
11
EXPLODED VIEW OF AMP
REMOVE THESE
SCREWS TO SEPARATE
REAR COVER FROM
AMP PLATE
00537
AC SOCKET
JC0129
FUSE HOLDER
FH0012
FUSE 3A 1.25 x .25
FS0022
POWER SWITCH
SR0032
AMP COVER
930050
00532
High Level
Binding Posts-JC0070
(set of 8 cluster)
Dual RCA jacks-
JC0049
Switch-SPDT TOGGLE (4)
SR0007
