MSW-1
8
MECHANICAL/PACKAGING PARTS LIST
Item Number Description Part Number
MECHANICAL
1 CABINET (CHARCOAL OR PLATINUM) Not for Sale
2 SCREW, (3) 905401-006
6-19x .375, MS, PPH, H/L, BLK
3 VOLUME CONTROL PCB 336787-001
4 12” WOOFER C.M.M.D.,SHIELDED, DCR = 3.4Ω ±10% 336786-001
5 FRONT BAFFLE (Charcoal) 336771-002
(Platinum) 336771-001
6 SCREW, (6) 905401-006
#8 x .75, PB, PPH, BLK
7 GRILLE CUP (6) (Charcoal) 336880-002
(Platinum) 336880-001
8 SCREW, (8) 905401-006
#8 x .75, PB, PPH, BLK
9 PORT TUBE 336804-001
10 SCREW, (4) 903101-016
#8 x 1, PB, TRPH, BLK
11 FOOT PAD (4) 334192-001
12 FOOT (4) (Charcoal) 334186-004
(Platinum) 334186-003
13 AMPLIFIER ASSEMBLY Not for Sale
14 SCREW, (10) 905401-006
#8 x .75, PB, PPH, BLK
15 GRILLE (Charcoal) 336770-002
(Platinum) 336770-001
PACKAGING
16 SYSTEM, 4+1-MODULUS SAT/CTR
17 OWNER’S MANUAL 336782-001
18 SURVEY CARD 335868-002
19 WARRANTY CARD 335841-001
20 RABOS KIT 335852-002
21 END PAD, TOP 336784-001
22 SYSTEM CARTON 336779-001
23 END PAD, BOTTOM 336784-002
24 POWER CORD 336658-115
