Infinity Modulus MSW-1

MSW-1
24
ELECTRICAL PARTS LIST
Part# Reference Designator Qty Description
PCB, FEATURE MAIN
SEMICONDUCTORS
UA0003 U5,U6 2 OPAMP, QUAD 14PIN DIL LM324N
UA0009 U1,U2 2 OPAMP, QUAD 14P DIL TL074/084
QM0035 Q5 1 JFET, N-CH J111 TO92 TR
DS0001 D9,D100,D101,D102,D103,D104, 9 RECT, 100mA 75V SIGNAL 1N4148T
D105,D200,D201
DZ0002 Z200 1 ZENER, 500mW 12V 5% 1N5242B
DZ0014 Z100 1 ZENER, 500MW 14V 5% 1N5244B
CAPACITORS
CC0020 C200 1 CAP, CA 470PF 100V 5%
CC0025 C203 1 CAP, CA 1000PF 100V 10%
CC0072 C1,C2,C4,C20,C100,C101 6 CAP, CA 100PF 100V NPO 10%
CC0082 C201 1 CAP, CA .1UF 50V 20%
CE0013 C204 1 CAP, E 47UF 50V 20% 5MMLS
CE0101 C16,C19 2 CAP, E 4.7UF 50V 85D 5X11 5MML
CE0103 C102 1 CAP, E 100UF 35V 85DEG 5MMLS
CE0108 C3,C5 2 CAP, E 4.7UF 16V BIPOLAR 5X11
CF0104 C12,C13 2 CAP, F 1UF 63V 5% 5MMLS
CF0125 C6,C8 2 CAP, F .068UF 100V 5% 5MMLS
CF0128 C7,C9 2 CAP, F .033UF 100V 5% 5MMLS
RESISTORS
RC0001 R211 1 RES, CF 1K0 1/2W 5%
RC0273 R1,R4,R20,R24 4 RES, ZERO OHM 1/4W
RC0290 R206 1 RES, CF 9M1 1/4W 5%
RM0001 R33 1 RES, MF 1K00 1/4W 1%
RM0002 R12,R13,R37,R38,R39,R100,R101,R102,R208,R209 10 RES, MF 10K0 1/4W 1%
RM0003 R200,R210 2 RES, MF 15K0 1/4W 1%
RM0011 R103,R105,R201 3 RES, MF 100K 1/4W 1%
RM0024 R207 1 RES, MF 2K21 1/4W 1%
RM0027 R17,R18,R22,R23 4 RES, MF 33K2 1/4W 1%
RM0031 R204 1 RES, MF 3K32 1/4W 1%
RM0045 R104 1 RES, MF 7K68 1/4W 1%
RM0065 R30 1 RES, MF 200R 1/4W 1%
RM0075 R205 1 RES, MF 475R 1/4W 1%
RM0079 R76 1 RES, MF 750R 1/4W 1%
RM0085 R107 1 RES, MF 2K00 1/4W 1%
RM0120 R9,R10 2 RES, MF 30K1 1/4W 1%
RM0136 R202 1 RES, MF 150K 1/4W 1%
