MSW-1
26
ELECTRICAL PARTS LIST (Cont.)
Part# Reference Designator Qty Description
RESISTORS
RC0273 R19,R20,R35,R36 4 RES, ZERO OHM 1/4W
RM0001 R12,R13,R14,R15,R28,R29,R30,R31 8 RES, MF 1K00 1/4W 1%
RM0002 R1,R2,R5,R6,R22,R38,R41,R42 8 RES, MF 10K0 1/4W 1%
RM0021 R7,R8,R23,R24 4 RES, MF 1K82 1/4W 1%
RM0024 R17,R18,R33,R34 4 RES, MF 2K21 1/4W 1%
RM0027 R21,R37 2 RES, MF 33K2 1/4W 1%
RM0029 R9,R10,R25,R26 4 RES, MF 3K01 1/4W 1%
RM0144 R43 1 RES, MF 47K5 1/4W 1%
RM0180 R16,R32 2 RES, MF 4K99 1/4W 1%
RP0059 R11,R27 2 POT, 2K 8MM TOP ADJ/COVER
RX0048 R39,R40 2 RES, MO 330R 1W 5%
Miscellaneous
JH0016 J7 1 CNCTR, HEADER 2PIN .100CTR
JH0074 J13,J14 2 CNCTR, HEADER 8PIN LOCKING .1C
MM0025 J9,J10 2 MISC, PC MT SCREW TERM 6-32
MT0003 J1 1 TERM, FASTON MALE PCMT 250X032
MT0023 J3,J6 2 TERM, FASTON MALE PCMT 187X032
MT0036 J2 1 TERM, FASTON MALE PCMT 205X032
PCB, POWER SUPPLY
SEMICONDUCTORS
DR0086 D6,D7 2 RECT, 1A 600V ULTRAFAST MUR160
DS0001 D2,D10 2 RECT, 100mA 75V SIGNAL 1N4148T
DS0002 D5,D8,D9 3 RECT, 100MA 200V SIGNAL 1N3070
DZ0004 Z1 1 ZENER, 500mW 18V 5% 1N5248B
DZ0021 Z2,Z3,Z4,Z5 4 ZENER, 500MW 15V 5% 1N5245B
QB0002 Q2 1 TRANS, NPN 40V .6A TO92 2N4401
QB0014 Q6 1 TRANS, PNP TO92 MPSA92TR
QB0017 Q3 1 TRANS, NPN 150V 0.6A 2N5551TR
DD0003 D4 1 RECT, 1A2 60V DIAC
DR0026 D3 1 RECT, 16A 200V CATHODE FEP16DT
DR0087 D1 1 RECT, 15A 200V ULTRA MUR1540
HC1011 U1 1 HYBRID, THK FILM HC BUCK CNTR
QM0004 Q4,Q5 2 MOSFET, IRF740 TO220AB
QM0020 Q1 1 MOSFET, IRF540 TO220AB
CAPACITORS
CC0025 C2 1 CAP, CA 1000PF 100V 10%
CC0040 C11 1 CAP, CA 4700PF 100V 10%
CC0059 C3,C4,C5,C18 4 CAP, CA .1UF 100V 20%
