Infinity Overture 1 - Disassembly and Reassembly Guide

Wnfinity
a
Overture1
-
MAR
24
1998
Single
Level
Bill
of
Materials
Page
4
Procedure:
PDC-R-07
-
Account:
ELP54
Effectivity
Date
:
03-24-98
S$A0309151 - Axial Sequence
Item.. X ..Part Number... Rev .Quantity. ...Alt-Part#... .... Reference Designator.... .UM. ECO No. ECO Date Strt Use
Description Inv Oper# Yields
P $A0309151 00 1.0000 EA
Axial Sequence Snowball 1
0 D11004 00 1.0000 EA
DIODE ZENER 6.2V 1/2W T/R 10 ZD2 100.00
0 011060 00 9.0000 EA
Diode Switching 500mW 75V 10 D1,2,4,5,6,7,8,9,11 100.00
T/R
0 DI1089 00 1.0000 EA
Diode 1N4003 1A 200 PIV 10 bD10 100.00
0 011101 00 2.0000 EA
DIODE ZENER 10V 1/2W T/R 10 2D3,5 100.00
0 PC1174 B 1.0000 EA
PC Board Snowball |! 10 100.00
0 RS1036 00 1.0000 EA
RES M/F 36 ohm 5% 1/4W 10 R74 100.00
T/R
0 RS1058 00 1.0000 EA
RES M/F 51.1Kohm 1% 1/4W 10 R63 160.00
T/R
0 RS1063 00 1.0000 EA
RES M/F 1 Mohm 1% 1/4W 10 R39 100.00
T/R
0 RS1150 00 1.0000 EA
RES M/F 43.2Kohm 1% 1/4W 10 R56 100.00
T/R
0 RS1153 00 1.0000 EA
RES M/F 47.5Kohm 1% 1/4W 10 R29 100.00
T/R
0 RS1161 00 1.0000 EA
RES M/F 11Kohm 1% 1/4W 10 R21 100.00
T/R
0 RS1268 00 1.0000 EA
RES M/F 2.21Kohm 1% 1/4W 10 R66 100.00
T/R
0 RS1342 00 1.0000 EA
RES M/F 9.09Kohm 1% 1/4W 10 R52 100.00
T/R
0 RS1351 00 1.0000 EA
RES M/F 13Kohm 1% 1/4W 10 R48 100.006
T/R
0 RS1353 00 3.0000 EA
RES M/F 3.01Kohm 1% 1/4W 10 R50,51,57 100.00
T/R
0 RS1357 00 1.0000 EA
RES M/F 100 ohm 1% 1/4W 10 R54 100.00
T/R
(5
