Infinity Overture 2 Service Manual

Wiring Diagram/Crossover Network Schematic (230V)
-IN
+IN
-MF
+MF
5
3
2
1
-HF
+HF
.205
.250
6
4
+MF
-MF
L1
0.68 mH
C1A
200 uF
50V
C2
10 uF
100V
L3
3.7 mH
C3
300 uF
50V
C4B
30 uF
100V
R1
8 ohms
5W
C5A
10 uF
50V
L4
0.1 mH
R2
2 ohms
5W
00423
AMPLIFIER
.250
-LF
.205
+LF
BROWN -
YEL/BLK +
CROSSOVER NETWORK
SCHEMATIC (230V)
C4A
30 uF
100V
C5B
10 uF
50V
C1B
200 uF
50V
L2
10 mH
YEL -
.205
.250
-LF
+LF
AMPLIFIER
WOOFER (2)
333773-001
MIDRANGE
TRANSDUCER (2)
330650-001
TWEETER
333232-001
YELLOW -
BROWN -
YEL/BLK +
+
WIRING DIAGRAM (230V)
+-
NETWORK
6 PIN HEADER
+
Overture 2
29
