Overture 3
11
Mechanical Parts List
Ref No. Description Qty Part No.
1 CABINET NOT FOR SALE
2 6.5”, WOOFER, B160-4 (120V) DCR = 14.2Ω±10% 4 330618-001
6.5”, WOOFER, LM-B160-8 (230V) DCR = 40Ω±10% 4 333773-001
3 SCREW, #8 x .75”, PPH, ZINC 25 900102-012
4 REAR WOOFER GRILLE 2 330955-001
5 FRONT/REAR WOOFER BAFFLE 4 332334-001
6 AMPLIFIER CAP 1 331399-001
7 CROSSOVER NETWORK (120V) 1 334416-001
8 BASE, FRONT FOOT 1 331184-001
9 REAR BASE 1 331075-002
10 REAR BASE w/PORT 1 331236-001
11 BINDING POST (RED) 1 331723-001
12 BINDING POST (BLACK) 1 331724-001
13 SCREW, #8 x 1” PPH, ZINC 15 900102-016
14 SCREW, #6-32 x 3/8” PPHMS CADCAD PLATED 2 10811
15 AMPLIFIER 1 NOT FOR SALE
16 1” (25MM) NEODYMIUM TWEETER DCR = 3.6Ω±10% 1 333232-001
17 UPPER FRONT BAFFLE (120V) 1 331182-001
UPPER FRONT BAFFLE (230V) 1 332335-002
18 FRONT GRILLE 1 333584-001
19 SCREW, #6 x 3/4” PPHD, BLK 20 63563
20 SCREW, 4-40 x .25” PPH, ZINC 2 905502-004
21 5.25”,MIDRANGE TRANSDUCER, B125-6 DCR = 7.7Ω±10% 2 330650-001
22 MIDRANGE CUP (120V) 1 330833-001
23 HI-FREQ. TWEETER GASKET 1 331725-001
PACKAGING
24 SPIKE FOOT SET, 1.5” 1 331360-001
25 OUTER CARTON (120V) 1 331246-001
26 FOAM PAD, TOP 1 331254-001
27 FOAM PAD, BOTTOM 1 331255-001
28 SURVEY CARD 1 330033-001
29 OWNER’S MANUAL (120V) 1 332293-001
30 SAFETY SHEET 1 330100-001
31 LINE FUSE 5A 2AG SLO-BLO (120V) 2 FS1068 or 331925-001
