Overture 3
3
Specifications
Overture 3 Frequency Response: 25Hz - 20,000Hz (±3dB)
Recommended Amplifier Power Range 10-200 watts*
Amplifier Peak Output: 500VA
Maximum Output: 115 dB SPL
Sensitivity: 94 dB 2.83V @ 1 meter
Nominal Impedance: 8Ω
Crossover Frequencies: 350 and 3,000Hz
Low-Frequency Driver: (4) 6-1/2” (165mm) high efficiency,
dynamically balanced, magnetically
shielded woofers.
Midrange Driver: (2) 5-1/4” (125mm) high-efficiency,
magnetically shielded midrange drivers.
High-Frequency Driver: (1) 1” (25mm) soft dome, high-
efficiency, neodymium magnet,
magnetically shielded tweeter.
Dimensions (H x W x D): 46" x 6-7/8" x 15-3/4"
(1,168mm x 175mm x 400mm)
Weight: 59 lb/(26.8 kg)
Power Consumption: 300 watts (Maximum)
* The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.
